Kit Upgrade IRIS with Adapter (2)
6600-0498-800
Maternal Infant Care
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Does not contain any burrs and sharp edges
  • Durable and reliable
  • Cuffs and other components can be cleaned with a mild detergent solution
  • RoHS compliant

Product Overview

  • The Adapter Assembly comes as a part of the IRIS porthole in an Infrared Incubator. The Infant Incubators provide heat in a controlled manner to neonates who are unable to thermoregulate based on their own physiology. It is installed in the porthole to avoid warm air escaping the Incubator. The inner wall and the standard porthole are removed and the latch is removed by unscrewing the two mounting posts on either side of the porthole frame. Using the existing porthole mounting posts, the iris adapter is mounted to the outside of the hood. The tightening ring snaps into the IRIS frame to tighten the cuff. The frame mounts to an adapter and mates to the ring. The ring turns smoothly with minimal effort. The PVC film is sealed into an approximate 7 inches diameter cylinder and then the elastic material is sewed to the film on both ends in the cuff.
