Ion Chamber with 24m interconnecting cable 5765924-2

5765924-2
2252611-3 2259298-8
X-Ray
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Field Replaceable Unit (FRU)
  • Low output variations
  • High sensitivity
  • Adjustable Gain

Product Overview

The Ion chamber assembly with 24m interconnecting cable is used in Precision 500D Wall stand and other R & F products manufactured by General Electric Healthcare (GEHC). The Ion chamber assembly incudes Ion-Chamber, Output Cable and connector, Service Manual, Spacers and a 24m interconnecting cable. The preamplifier circuitry is integrated directly into the Ion Chamber. This preamplifier circuitry is protected against X-ray direct radiation by an internal electronic shielding. A male Modu 15 position connector is used to interconnect the ion-chamber with the GEMS (General Electric Medical Systems) system. An additiona 24m interconnecting cable between the Ion Chamber and the generator is provided with this assembly, the cable has a 14 pin femal Modu connector at one side and M Series 14 position female connector at other side . The Ion chamber also featured with 3 POTs at the left side for adjustment. The spacers included in the assembly are Hexagonal Spacers and Tubular Spacers.

Substitute Parts :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
2252611-3

2252611-3

2259298-8

GE Part

2259298-8
