Scan Disk Array, Hard Drive with Mounting Sled Firmware Rev1

5114536-11
5114536-10
PET/CT
GE Healthcare
Exchange - Return Defective
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Highly reliable
  • Fetch data very fast
  • Very high rotational speed
  • 300 GB drive capacity

Product Overview

  • The Scan Array, Hard Drive with mounting sled firmware rev1 is used in Computed Tomography. The capacity of the Hard disk drive is 300.0 GB. The interface of storage used is SAS (Serial Attached SCSI), which is a point-to-point serial protocol that moves data to and from computer-storage devices such as hard drives and tape drives. The read latency is 2.0 milliseconds. The disk array is considered a commercial off-the-shelf (COTS) subassembly. The disk array weighs 60 Lbs (27.2 Kgs), and the rotational speed of the drive is 15000 RPM. The exhaust fans used in the disk array are DC fans which are brushless and have ball bearings. The disk array supports twelve (12) external 3.5-inch hot-swap SCSI HDD, two (2) hot-swap rear blowers for optimized cooling, two (2) external 68-pin HD68 SCSI connector, AC power source. It operates under the temperature range of 5-35˚ C and can accept temperature change of 3˚ C per hour. The chassis type of the disk is Rock-mountable, whose orientation is horizontal. The hard drives are hot-swappable, which means the disks can be replaced while the disk array is still in use, from the front of the disk array. LEDs are available to check the functioning of the disk drives.

Compatible Products

VCT

VCT

Lightspeed Ultra

Lightspeed Ultra

Lightspeed Plus

Lightspeed Plus

Lightspeed QXi

Lightspeed QXi

Discovery ST

Discovery ST

Discovery ST (64 Slice)

Discovery ST (64 Slice)

Discovery ST (128 Slice)

Discovery ST (128 Slice)

Substitute Parts :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
5114536-10

Scan Disk Array, Hard drive with mounting sled, Seagate S
