Helios Chassis to Chassis Cable 2193036

2193036
Computed Tomography (CT)
GE Healthcare
Outright
Add to Wish List
Login To Shop
Login To Shop
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Flexible Flat Ribbon Cable with PVC Jacket
  • Easy to Connect Micro-D 68 Position Connectors
  • 350 mm Length
  • Gold Plated Contacts assures good conductivity

Product Overview

This 350mm long flat ribbon cable assembly is made using 68 conductors of 38 AWG size with 2 identical male D-Sub Micro-D connectors at both ends. The entire gray cable assembly and connectors are shielded to minimize EMI/RFI interference. In addition, using Gold Plated contacts with Tinned Copper Solid conductors assures good conductivity and efficient functioning. This Helios Chassis To Chassis Ribbon type cable assembly is used to connect the left and right chassis assembly of the Scaleable Data Acquisition System (SDAS) and is used with GE's Lightspeed Computed Tomography (CT) systems.
